Satchell 106/Saxo BE4R Engine Mount Kit
€849.55
Tax Included
Satchell BE4R Engine Mount Kit for Peugeot 106 / Citroën Saxo
BE4R gearbox conversion with TU engine, keeping the engine in its OE position
| BE4R gearbox | No welding | OE position | 106 / Saxo |
Satchell Engineering's new TU/BE4R mount kit for the Peugeot 106 and Citroën Saxo keeps the engine in its OE position.
The key is the new short intermediate shaft, which lets the engine and gearbox sit square and level in the engine bay. This brings significant benefits when carrying out the BE4R gearbox conversion in the 106 and Saxo.
TOP MOUNT: the kit can be used with the OE top mount or with Satchell's billet mount, available as an option for the Saxo and phase 2 106.
Kit benefits
| More clearance: moves the inner CV cup away from the chassis rail. | |
| More balanced driveshafts: more even lengths on both sides of the car. | |
| Better CV angles: less movement on the inner CV and more droop travel. | |
| No welding, with the engine kept at its OE position and angle. |
Kit contents
| Top gearbox mount | Pin type, poly bushed |
| Rear gearbox bracket/mount | Poly bushed |
| Additional 4th rear mount | Poly bushed, integrated into the intermediate bearing carrier |
| Intermediate bearing carrier | Billet alloy, natural hard anodised finish, supplied with hockey stick type bearing retainer bolts |
| Intermediate shaft | 60 mm shorter |
| Driveshaft bar | Satchell competition specification, in any length required: standard track through to full Maxi width |
| Outer joints | Larger, stronger 406/306 type BE joints rather than the smaller 205 option. For use with Satchell BE drive flanges for MA hubs, or any of their full suspension kits |
Technical specifications
| Vehicles | Peugeot 106 / Citroën Saxo |
| Engine / gearbox | TU engine with BE4R gearbox |
| Engine position | OE (position and angle) |
| Welding | Not required |
| Engine top mount | OE, or optional Satchell billet mount (Saxo / phase 2 106) |
| Weight | 8.0 kg |
| Satchell reference | BE4R |
Versions: kit with intermediate bearing carrier and complete long shaft, or the same kit with billet engine top mount (Saxo / phase 2 106).
