RPBT003FS Formula Student Electronic Throttle Pedal
€152.89
Tax Included
Racing Pedal Boxes RPBT003FS electronic throttle pedal for electric Formula Student (FSAE) cars. Welded high-strength steel, ready for two linear position sensors, with two return springs and an adjustable mechanical stop. Sensors not included.
RPBT003FS Formula Student Electronic Throttle Pedal
Drive-by-wire throttle for electric FSAE cars
| Formula Student | Dual sensor | Dual spring | 1.05 kg |
The Racing Pedal Boxes RPBT003FS electronic throttle pedal is designed for Formula Student FSAE, for electric cars with drive-by-wire systems.
It is made from welded high-strength steel parts with a lightened design, and is ready to take two linear position sensors and two return springs, as the technical rules require.
SENSORS NOT INCLUDED: the pedal accepts sensors with an extended length of 120 to 210 mm, 25 to 40 mm of travel and Ø4 mm connections.
FSAE rules compliance
| Two independent linear position sensors (rule T11.8.5). | |
| Adjustable mechanical stop that prevents the sensors from being damaged or overstressed (rule T11.8.4). | |
| Two return springs included: each one works even if the other is disconnected (rule T11.8.4). |
Features
| Suitable for KPM12J linear sensors (ref. RPBAC11), sold separately. | |
| Large non-slip pedal face to make heel-and-toe easier. | |
| Adjustable pedal angle, up to 22 degrees. | |
| Floor mounted with 4 M6 bolts. | |
| Anti-corrosion treatment on every part. |
Technical specifications
| Use | Formula Student FSAE (electric) |
| Material | Welded high-strength steel |
| Sensors | 2 linear (not included), KPM12J compatible |
| Extended sensor length | 120 to 210 mm |
| Sensor travel | 25 to 40 mm |
| Sensor connection | Ø4 mm |
| Return springs | 2 (included) |
| Pedal angle | Adjustable, max. 22° |
| Mounting | Floor, 4 M6 bolts |
| Pedal weight | 1.05 kg |
| Brand | Racing Pedal Boxes |
| Reference | RPBT003FS |
